Bench notes
One rule per note. A few panels, a short note in his own words, and the sources underneath. Start anywhere.


Bench note No. 1
Never Force a Stuck Cartridge
It is stuck for a reason. Loosen it, or let a puller do the pulling.

Bench note No. 2
Two Wrenches, Then Count the Turns
Hand tight, then the maker's number: 3/4 turn by BrassCraft's sheet, about 1/2 turn after the sleeve grabs by Oatey's. The sheet in your box wins.

Bench note No. 3
Grease the O-Rings
Silicone grease, a small dab. Nothing with petroleum in it, ever.

Bench note No. 4
Read the Old Part Before You Throw It Out
A faucet that keeps eating washers has a damaged seat. Your fingernail finds it. A seat wrench or a seat dresser fixes it.

Bench note No. 5
Find Every Shutoff, Then Work the Main Like a Pro
The count says the gate made its whole trip. Stiff? Ease the packing nut a quarter to half turn. Force an old one and the stem unscrews from the gate.

Bench note No. 6
Sleeve the Cold Pipes Before the Freeze
Foam slows the cold down and buys you time. It does not make heat.

Bench note No. 7
Cut Square, Deburr, Mark the Depth
A push fitting holds only what you give it: a square, clean pipe end pushed all the way home.

Bench note No. 8
Hand Tight Means Hand Tight
The plastic nuts on a toilet get fingers, by Fluidmaster's and Korky's sheets, and TOTO says hand tight on the supply nut. Fluidmaster says a cranked one can break and cause a flood.

Bench note No. 9
No Ratchet Cutter on Cold CPVC
Below 50 degrees F, Wavin says never use one. Lubrizol says it squeezes the pipe, and cold CPVC can crack. Cut with a wheel cutter made for plastic or a fine tooth saw, and cut at least two inches past any crack.
